General Specs |
| Width (in.) | 23.63 |
| Height (in.) | 44.75 |
| Duct Size (in.) | 6" Round |
| Depth (in.) | 19.75 |
| Color | Stainless Steel |
| MPN | 10743180 |
| Appliance Fit Width (cm.) | 60 |
| Manufacturer Warranty | 1 Year Parts & Labor |
| Color Finish Name | Stainless Steel |
| Range Hood Type | Wall Mounted |
| ADA Compliant | No |
| ENERGY STAR Certified | No |
| Appliance Fit Width (in.) | 24 |
| Product Weight (lbs.) | 47 |
| Bulb Type | LED |
| Fan Speed Options | 4 |
| Width (cm) | 60.02 |
| Height (cm.) | 113.67 |
| Depth (cm.) | 50.17 |
| Product Weight (kg) | 21.32 |
| Voltage | 120 |
| Frequency | 60 |
| Range Hood Features | Automatic Shut Off, Light, Removable Grease Filter, Ductless Capable |
| Ventilation Type | Ductless |
Technical Data |
| Maximum overall hood height for vented and external in (mm) | 39 5/8 (1005) |
| Maximum overall hood height for recirculation in (mm) | 44 3/4 (1135) |
| Minimum overall hood height for vented and external in (mm) | 27 (685) |
| Minimum overall hood height for recirculation in (mm) | 32 1/8 (815) |
| Canopy height in (mm) | 2 1/2 (62) |
| Length of power cable in m | 4 (1.5) |
| Standard plug fitted | Yes |
| Fuse rating in A | 15 |
| Number of phases | 1 |
Operating Modes |
| Recirculation conversion kit (order separately) | DUW 20 |
| Active charcoal filter (order separately) | DKF 12-P |
| Type of air guide | Convertible |
User Convenience |
| Electronic controls | Yes |
| Programmable booster level switch-off | Yess |
Filter System |
| Number of dishwasher-safe stainless steel grease filters (10-ply) | 1 |
Lighting |
| Number of lights x W | 2 x 3 W |
| Light intensity in Lx | 330 lx |
| Colour temperature in K | 3000 Kelvin |
Fan |
| Dual-action fan | Yes |
| AC motor | Yes |
Installation Notes |
| Vent connection at top and rear | Yes |
| Telescopic chimney | Yes |
Accessories Supplied |
| Non-return flap | Yes |
